Are Gnotobiotic Isolators Always Necessary?

Alexander Maue, PhD
Wednesday, March 1st, 2017
Are Gnotobiotic Isolators Always Necessary? Housing system design is fundamentally linked to the stability and characteristics of the mouse microbiome - but are gnotobiotic isolators always necessary to prevent compositional changes in microbiota?

A new study published by Randi Lundberg, DVM and co-authors from University of Copenhagen and Technical University of Denmark, characterized the gut microbiota of mice housed in individually ventilated cages (IVCs) and compared it to that of mice housed in a gnotobiotic isolator1. The objective of their study was to assess whether mice with complex specific pathogen free (SPF) microbiotas, or mice which have undergone fecal microbiota transplantation (FMT) for microbiome research, would be resilient to compositional changes of the microbiota when housed in a conventional IVC system for SPF mice.

The authors used germ-free mice and FMT to establish a cohort of mice with a controlled baseline microbiota.

IVC Systems Can Provide Protected Housing For Gnotobiotic Mice

“Experimental design for microbiome studies must take into careful consideration which type of housing system is most appropriate for the type of study being conducted. The housing system can have profound influence on the outcome of the study.”
–Randi Lundberg, DVM
Other investigators tested specialized IVC systems for gnotobiotic husbandry and showed that mice can remain germ-free in these systems for up to 12 weeks2,3 – if supported by equipment designed for gnotobiotic procedures and extremely dedicated efforts from highly specialized staff.

In contrast, the study by Lundberg et al. was performed under more manageable clean conditions in an SPF facility. Nevertheless, the authors found that the gut microbiota of the mice housed in IVCs was not more diverse regarding operational taxonomic units (OTUs) than that of the mice housed in a gnotobiotic isolator.

The authors also noted that, compared to the isolator-housed mice, no additional OTUs were found in the IVC-housed mice that were not also found in the original FMT donor material. However, the authors analyzed the bacterial microbiota by 16S rRNA gene sequencing – a method that is good for detecting overall compositional changes, but less precise for determining potential contamination.

Does the Microbiome Evolve Differently in IVCs and Gnotobiotic Isolators?

The team analyzed the microbiota composition of the germ-free founder mice colonized by FMT and the subsequent two offspring generations. Therefore the study provided insight into microbiota dynamics across multiple cages over time in the IVCs compared to the isolator.

The authors noticed that temporal dynamics seemed most pronounced in the IVC-housed mice. This is equivalent to another study, though not performed in IVCs, which showed that cage effect cannot be eliminated by FMT of the founder mice4. Cage effect is the phenomenon that the microbiota of co-housed mice is more similar to one another than to that of mice in other cages.

In the long run, the confined cage environment of IVCs may cause temporal dynamics that are less apparent in isolators, because microbes are shared between open-top cages in the isolator. For long-term studies, the suggested time effect on the microbiota in IVCs may be worth considering, though the biological relevance remains to be investigated.

Considering Microbiological Study Units in Study Planning

The paper is interesting for researchers working with mice harboring specific microbiotas for certain research purposes. In some cases, IVC-housing of gnotobiotic mice with complex microbiotas may be a viable alternative to isolators, which are highly resource-demanding.

The paper also justly discusses the advantages and disadvantages of IVCs and isolators from an experimental design point-of-view. Mice housed in one gnotobiotic isolator comprise one microbiological study unit, which poses a possible limitation in experimental design. In contrast, an experimental cohort housed in multiple IVCs provides multiple microbiological study units and, as such, a stronger experimental design – if the microbiological status is not compromised.

Related White Paper Download the Taconic Biosciences' White Paper:
1. Lundberg R, Bahl MI, Licht TR, Toft MF, Hansen AK. Microbiota composition of simultaneously colonized mice housed under either a gnotobiotic isolator or individually ventilated cage regime. Sci Rep. 2017 Feb 7; 7: 42245.
2. Hecht G, Bar-Nathan C, Milite G, Alon I, Moshe Y, Greenfeld L, Dotsenko N, Suez J, Levy M, Thaiss CA, Dafni H, Elinav E, Harmelin A. A simple cage-autonomous method for the maintenance of the barrier status of germ-free mice during experimentation. Lab Anim. 2014 Oct;48(4):292-7.
3. Paik J, Pershutkina O, Meeker S, Yi JJ, Dowling S, Hsu C, Hajjar AM, Maggio-Price L, Beck DA. Potential for using a hermetically-sealed, positive-pressured isocage system for studies involving germ-free mice outside a flexible-film isolator. Gut Microbes 2015 Jul 4;6(4):255-65.
4. McCafferty J, Mühlbauer M, Gharaibeh RZ, Arthur JC, Perez-Chanona E, Sha W, Jobin C, Fodor AA. Stochastic changes over time and not founder effects drive cage effects in microbial community assembly in a mouse model. ISME J. 2013 Nov;7(11):2116-25.
